BioSafe Systems - Fog-It 6 Wall-Mount Fog System

Brand: BioSafe Systems

Fog-It 6 Wall-Mount Fog System

The BioSafe Systems Fog-It 6 is a wall-mounted fogging system built around a timer-controlled control box that feeds a network of fog nozzles. It draws from a pre-mixed solution and produces an ultra-fine fog of about 15 microns at 50 psi for treating entire rooms on a set schedule.

Install the control box and the number of nozzles your space needs to fog BioSafe Systems activated peroxide solutions through storage rooms, greenhouses and indoor cultivation spaces. The control box is supplied with Kalrez pump seals for chemical compatibility, and fog nozzles are sold separately so the system can be scaled to the room.

Available Options

• Control Box (Kalrez Seals)
• Fog Nozzle

Key Features

• Powered by compressed air and 120 VAC electricity (2 amps)
• Single-shot timer with delay-on-make for scheduled fogging
• Quick-change pump, Kalrez pump seals
• Draws from pre-mixed solution through an 8 ft suction line
• Supports up to 20 nozzles per control box (OEM spec)
• 15 micron droplet size and 7.9 oz/min per nozzle at 50 psi (OEM spec)
• Air use of 2 cfm for the control box plus 2.5 cfm per nozzle (OEM spec)
• 1 liter of solution covers approx. 1,000 cubic feet

Ideal Applications

• Cold storage and post-harvest storage rooms
• Greenhouses and headhouses
• Indoor cultivation and controlled-environment agriculture rooms
• Scheduled whole-room sanitation programs
