TrolMaster - Mini Controller Cabinet (100-277V)(SCC-4)

Brand: TrolMaster

TrolMaster Mini Controller Cabinet, 100-277V (SCC-4)

The TrolMaster SCC-4 Mini Controller Cabinet is a compact, all-in-one enclosure for TrolMaster controllers including the Green-X (GCS-1), Hydro-X (HCS-1), Aqua-X (NFS-1), Carbon-X (CDA-1) and Tent-X (TCS-1). It holds the main controller and up to 6 DSR-1 Relay Device Stations.

The SCC-4 provides a professional installation platform that keeps wiring and device modules neatly arranged, clean and dry. Built-in RJ12 splitter boards, an IP53 rating and intelligent fan speed control simplify setup and maintenance.

Available Options

• Model: SCC-4
• Includes: mini controller cabinet, HCS-1/NFS-1/CDA-1/TCS-1 power cable (1 ft, DC6x4mm), GCS-1 power cable (1 ft, DC5.5x2.1mm to DC6x4mm) and three 1.6 ft RJ12 cables
• Compatible controllers: HCS-1, NFS-1, CDA-1, GCS-1 (also Tent-X TCS-1 per manufacturer)

Key Features

• IP53 rated protection
• Supports up to 6 DSR-1 Relay Device Stations
• Built-in RJ12 splitter boards: 6, 6 and 5 ports
• Intelligent fan speed control
• Input voltage: 100-277V, 50/60Hz; output current: 60A
• Expandable, customizable layout with clean cable management
• Working environment: 32 to 104 deg F, 90% humidity or less

Ideal Applications

• Compact enclosures for Hydro-X, Aqua-X, Carbon-X, Green-X or Tent-X installations
• Housing relay device stations in smaller rooms and greenhouses
