Par Meter and Spectrometer

Brand: Mammoth Lighting

Introducing our cutting-edge Par Meter and Spectrometer, a technological marvel crafted for precision and performance. Engineered with a high-speed CPU processor and a high-precision electronic CCD optical sensor, this device operates on the principle of long focal cross asymmetric CT spectroscopy system, delivering unparalleled accuracy and stability.

Enjoy the savings vs others at $500+ for just Par readings!

* Extension wands are sold out - but an inexpensive selfie stick works very well too *

Key Features:

1. Advanced Optical Technology:

• Optical resolution of 2nm for precise measurements.
• Wider wavelength range ensures comprehensive analysis.
• Stable performance under various conditions.

2. Electronic Shutter Technology:

• Minimum integration time as low as 50us, allowing measurement of strong and weak optical signals.
• Adjustable integration time for versatility in signal detection.

3. Sleek and Portable Design:

• All-aluminum alloy precision carving for a lightweight and portable body.
• Modern design, completely discarding the bulk of traditional models.

4. Open Operating System:

• Upgraded system with a more open operating system and source code.
• Facilitates intelligent product applications and provides space for unlimited instrument upgrades.

5. Intuitive User Interface:

• 3.5-inch high-definition IPS capacitive touch screen for a vibrant display.
• High resolution for more content on a single screen, realistic graphics, and a smoother user experience.
• Thoughtful interface design enhances usability.

6. Quick and Convenient:

• Quick on/off functionality for swift operations.
• One-click testing for seamless measurements.
• Large battery capacity allows for 24 hours of extended testing time.

Whether you're a professional researcher, scientist, or enthusiast, our Par Meter and Spectrometer redefine the standards of accuracy, convenience, and portability. Elevate your experiments and measurements with a device designed for the future of scientific exploration.

B. Function Description:

• PPFD PAR:

  • Measures Photosynthetic Photon Flux Density for optimal plant growth.

• Spectral Distribution Map:

  • Provides a detailed map of the spectral distribution for comprehensive analysis.

• Related Color Temperature Tc (K):

  • Offers color temperature information for accurate lighting assessment.

• Illuminance E (lx):

  • Measures the level of illuminance in lux for well-lit environments.

• Irradiance Ee (W/m²):

  • Determines irradiance for a complete understanding of light intensity.

• Chromaticity Coordinates (x, y):

  • Presents chromaticity coordinates for precise color representation.

• Relative Spectral Power Distribution P(λ):

  • Illustrates the relative distribution of spectral power.

• Color Rendering Index Ra, Ri (i=1-15):

  • Evaluates color rendering accuracy across a spectrum of indices.

• Color Rendering Index:

  • Measures the device's ability to reproduce colors accurately.

• Chromaticity Coordinate Map:

  • Displays a map of chromaticity coordinates for comprehensive analysis.

• Color Tolerance Map SDCM:

  • Illustrates color tolerance using Standard Deviation of Color Matching.

• Main Wavelength, Peak Wavelength, Half Width:

  • Provides crucial information about the light spectrum.

• Light to Dark Visual Ratio S/P:

  • Evaluates the visual experience by assessing light-to-dark ratios.

• Color Purity, Red Ratio, Green Ratio, Blue Ratio:

  • Analyzes color components to ensure accurate representation.

• Can Export Spectral Data per Nanometer:

  • Allows for detailed spectral data export for in-depth analysis.

• More Functional Parameters Can Be Customized:

  • Tailor the device to specific requirements with customizable parameters.

C. Main Technical Indicators:

• Model and Name:

  • M400 Spectral Color Illuminometer.

• Wavelength Range:

  • 380nm~780nm for comprehensive spectral coverage.

• Split Mode:

  • Long focal cross asymmetric CT split beam system.

• Sensor:

  • High-precision CCD for accurate light sensing.

• Spectral Bandwidth (FWHM):

  • 2nm for detailed spectral analysis.

• Spectral Resolution:

  • 0.2nm for high-resolution data.

• x, Y Coordinate Value x, y Accuracy:

  • ±0.0015 accuracy; ±0.0005 repeatability.

• Wavelength Accuracy:

  • ±0.5nm for precise wavelength measurements.

• Wavelength Data Output Interval:

  • 1nm; EXCEL can export data corresponding to each nanometer.

• Illumination Accuracy Level:

  • Level 1 (±4% reading ±1 reading) for reliable results.

• Color Rendering Accuracy:

  • ±1.5% for accurate color representation.

• Photosensitive Surface:

  • Ф 10mm for efficient light capture.

• Screen Type:

  • 3.5-inch high-definition IPS capacitive touch screen for intuitive operation.

• Chromaticity Standard Accuracy:

  • ±0.0025, traceable to NIM for reliable color temperature assessments.

• Color Temperature Range:

  • 1000K~100000K for versatile lighting conditions.

• Stray Light:

  • ≤0.3% to minimize interference.

• Illuminance Measurement Range:

  • 0.1Lux~2000Klux for diverse lighting environments.

• Measurement Mode:

  • Single test/continuous test for flexibility in testing scenarios.
