Dramm - PulsFOG Chemical Tank

Brand: Dramm

PulsFOG Chemical Tank

Replacement and spare solution tanks for Dramm's PulsFOG thermal foggers, in the four capacities Dramm builds. Which one you need is set by the machine rather than by preference: the hand carried standard and oil foggers run a single 10 liter tank, the BIO build splits its load into a 6 liter solution tank and a separate 5 liter tank of plain water, and the cart mounted K-30/20 machines carry two 55 liter tanks side by side. They are not interchangeable across those builds, so confirm the machine before ordering. Beyond replacing a cracked or chemically attacked tank, the usual reason to buy one is to hold a second tank per chemical program, which lets the next batch be mixed while the current one is still being fogged and takes the rinse step out between products.

Pick by machine. 10 Liter (K-10LCT) is the solution tank on every standard and oil portable: the K-10, K-22 and K-30 all carry 10 liters, and Dramm rates a full one at up to 50,000 sq ft of treatment. 6 Liter (F00242) is the BIO size and only the BIO size, because that machine runs a 6 liter tank of chemistry against a 5 liter tank of plain water whose second set of injection nozzles cools the exhaust so biologicals and heat sensitive products come through the pass intact, which is why a BIO fill covers up to 30,000 sq ft instead of 50,000. 5 Liter (K-05LCT) is the small tank for the hand carried machines and the lightest of the four at 2 lbs empty. 55 Liter (K-55LCT) is the cart tank, used in pairs on the K-30/20, and at 11 lbs empty it is the only one of the four that is a two hand lift once it is full. If you are buying spares rather than replacements, buy them one per chemical program rather than one per machine, because the tank costs less than the labor of flushing a line between a biological and a conventional product.

Specifications

Configurations

Key Features

• Four capacities cover the range, from the hand carried machines to the cart mounted K-30/20
• 6 Liter is the BIO solution size, the one capacity the standard and oil machines do not use
• 10 Liter is the standard and oil portable tank, rated at up to 50,000 sq ft per fill
• 5 Liter is the small hand carried tank, 2 lbs empty
• 55 Liter tanks ride in pairs on a K-30/20, so a refill is a tank swap rather than a walk back
• A spare tank lets the next batch be mixed while the current one is still being fogged
• A dedicated tank per chemistry removes the rinse between programs and the cross contamination risk with it
• Replaces a cracked or chemically attacked tank without sending the machine in for service

Ideal Applications

• Replacing a cracked or chemically attacked PulsFOG solution tank
• Running a second tank so a refill is a swap rather than a mix
• Keeping separate tanks for biologicals and for conventional chemistry
• Fogging heat sensitive products on a BIO machine, where the 6 liter solution tank works against the 5 liter water tank
• Cart mounted K-30/20 work, where two 55 liter tanks ride together
• Greenhouse, mushroom house and livestock housing programs that alternate products

These feed the PulsFOG Portable Thermal Fogger and the cart mounted K-30/20, and go with a VK-II or NutriFOG carrier solution, the PulsFOG chemical funnel (K-CF) that fills them and the PulsFOG dosage nozzle that meters what leaves them.
