Dramm - Kwik Spacer
Brand: Dramm
Kwik Spacer
Dramm: 'The Kwik Spacer slides into the Kwik Klamp and is used to create additional space between the pipe and wall.' It is a stackable standoff rather than a clamp - it does nothing on its own and is ordered in the same size as the Kwik Klamp it goes into. Made in the Netherlands from chemical resistant polypropylene.
The only choice is the Kwik Klamp size it slides into, which is itself named after the pipe: 1/2 in, 3/4 in, 1 in, 1-1/4 in, 1-1/2 in, 2 in, 3 in and 4 in. Size does not change how far the pipe stands off. Every spacer is 3/4 in tall whatever size it is - the published sizes differ only in footprint - so distance is set by how many you stack. Dramm: 'Multiple Kwik Spacers can be combined to create varying lengths in 3/4 increments.' Two on a 1 in clamp put the pipe 1-1/2 in off the surface, three put it 2-1/4 in off.
Specifications
| Sizes | 1/2 in, 3/4 in, 1 in, 1-1/4 in, 1-1/2 in, 2 in, 3 in and 4 in, matching the Kwik Klamp it slides into |
| Standoff per spacer | 3/4 in, the same on every size |
| Stacking | Spacers combine to build standoff in 3/4 in increments |
| Material | Chemical resistant polypropylene, made in the Netherlands |
| Overall size, published examples | 1 x 0.625 x 0.75 in on the 1/2 in; 1 x 0.875 x 0.75 in on the 3/4 in; 1.25 x 0.875 x 0.75 in on the 1 in; 1.25 x 1.625 x 0.75 in on the 1-1/4 in - all of them 0.75 in tall |
| Requires | A Kwik Klamp of the same size; the spacer does not mount pipe on its own |
Configurations
| Pipe Size | Part number |
|---|---|
| 1/2 in | KS-50 |
| 3/4 in | KS-75 |
| 1 in | KS-100 |
| 1-1/4 in | KS-125 |
| 1-1/2 in | KS-150 |
| 2 in | KS-200 |
| 3 in | KS-300 |
| 4 in | KS-400 |
Key Features
- Sets pipe standoff in 3/4 in steps by stacking
- Same 3/4 in height in every size, so the arithmetic does not change with pipe size
- Chemical resistant polypropylene, the same material as the clamp
- Covers the full 1/2 in to 4 in Kwik Klamp range
- Clears insulation, cladding or other services without a fabricated bracket
Ideal Applications
- Standing a supply pipe off a wall to clear insulation, cladding or other services
- Building up standoff in 3/4 in steps
- Keeping a chemical supply or wash-down line off a surface that gets sprayed or cleaned
The Kwik Spacer only works inside a Kwik Klamp of the same size, and both are listed by Dramm as PolyRail system parts; neither joins tubing, which is what the PolyLoc and EasyLoc fitting families do, and neither has anything to do with PipeLoc, Dramm's separate line for large PVC pipe.
