Dramm - JetRain Hanging Nozzle Assembly

Brand: Dramm

JetRain Hanging Nozzle Assembly

A pre-made hanging drop: a barbed JetRain complete nozzle - cone plus the 15-50 psi Clean Out Check Valve - already fitted to a length of PE leader tube. The barb goes into an overhead lateral and the nozzle hangs below it. Dramm's Hanging Nozzle System works this way so the nozzle hangs plumb under its own weight, which keeps the pattern from being distorted by a nozzle sitting at an angle, and so that neither the nozzle nor the lateral above it drips on the crop between cycles.

Two choices. Drop length is the leader tube: 36 inch, 48 inch or 60 inch. Dramm's guidance for its Hanging Nozzle System is to choose a length that puts the nozzle below the hanging baskets, or at least 3 ft above the crop when watering benches or ground beds, and to space the assemblies about 3 ft apart along the lateral. Nozzle color is the flow rate, measured by Dramm at 40 psi: White 0.48 gpm (1.8 L/min) and Blue 0.48 gpm (1.8 L/min) for propagation mist, Red 0.79 gpm (3.0 L/min) for mist and irrigation, Yellow 1.37 gpm (5.2 L/min) for heavier irrigation. Dramm's chart also gives a working window for how far a nozzle should sit above the crop when it is inverted, and the two choices interact there: 24 to 96 inches for White and Blue, 24 to 120 inches for Red, but 60 to 120 inches for Yellow. That Yellow minimum is the one that catches people, since a short drop over a tall crop puts the nozzle under its own range. Yellow is offered on the 36 inch and 48 inch drops only.

Specifications

Configurations

Key Features

• Nozzle, check valve and leader tube supplied as one assembled drop
• Hangs plumb under its own weight, so the pattern is not thrown off by an angled nozzle
• Check valve stops the drop dripping on the crop between cycles
• Barbed inlet punches straight into an overhead PE lateral
• Flexible PE leader rather than rigid pipe, so drops can be moved and rehung as crops change
• Three drop lengths and color-coded flow rates

Ideal Applications

• Watering hanging baskets from an overhead lateral
• Bench crops watered from a high lateral
• Ground bed irrigation where a rigid riser would be in the way
• Adding drops to an existing overhead PE line
• Mixed basket and bench houses on one lateral

The same barbed JetRain complete nozzle is sold on its own for punching directly into a PolyRail-supported line, and Dramm builds the same style of hanging assembly around its Pin-Perfect nozzles in the same three leader lengths.
