Dramm - JetRain 180 Degree Nozzle Tip

Brand: Dramm

JetRain 180 Degree Nozzle Tip

The tip from a 180 degree JetRain nozzle, sold on its own. It is the small orifice insert that sets the pattern and the flow, and it seats into an existing 180 degree JetRain cone - it is not a working nozzle by itself and does not include the cone, the check valve or an inlet. Growers stock it to refresh worn or plugged tips at the ends of runs without pulling whole nozzle assemblies out of the tubing.

Color is the only choice, and it should match the nozzle you are servicing so the flow and pattern of that position do not change. Dramm does not publish a flow rate for any of the five 180 degree colors - Brown, Green, Grey, Orange and Red are Dramm's coding for the 180 degree line, and the published JetRain flow chart covers the 360 degree colors only. Read the color off the nozzle in front of you and order to match. If the color has faded past reading, or the cone body itself is cracked or distorted, buy the 180 degree cone rather than a tip.

Specifications

Configurations

Key Features

• Restores a worn or plugged end-of-run nozzle for a fraction of a complete assembly
• Seats into the 180 degree cone already installed, so nothing is unpunched from the tubing
• Five color-coded options matching Dramm's 180 degree cone range
• Small enough to keep a full set on the shelf as pre-season spares

Ideal Applications

• Pre-season refresh of end-of-run nozzles
• Clearing chronically plugged 180 degree positions
• Restoring pattern on nozzles that have gone ragged with age
• Maintenance spares stock for a propagation or irrigation house

Goes into the 180 degree JetRain nozzle cone, sold separately; the complete 180 degree nozzle bundles cone, Clean Out Check Valve and inlet if the whole assembly needs replacing.
