Dramm - Hydra SprayTrax Electric 100 Gallon Sprayer
Brand: Dramm
Hydra SprayTrax Electric 100 Gallon Sprayer
The Hydra SprayTrax Electric 100 is a 100 gallon hydraulic sprayer on Dramm's four wheel self-tracking SprayTrax cart, driven by a 1.5 HP TEFC electric motor rather than a gas engine. Both axles steer, so the loaded unit turns 360 degrees inside a 7 ft circle, and 15 in turf tires let it cross soft floors and uneven ground without rutting. The stainless inner sleeved triplex piston pump is rated at 4 GPM and up to 550 psi. Choose this over the gas SprayTrax when the work is indoors or in enclosed ranges where engine exhaust is a problem.
The motor decides most of this order. 1Ph means single phase and 3Ph means three phase: 115V 1Ph plugs into ordinary shop power and covers most builds on the page, 230V 1Ph suits a single phase 230V circuit, and the 208V 3Ph and 230V 3Ph options need a three phase feed. The rpm in the option name is the motor's rated shaft speed, so 208V 3Ph 1750 rpm and 208V 3Ph 3600 rpm are the same supply with different motor speeds; Dramm's standard Hydra electric motor is a 1750 rpm unit. Then pick reel and fittings. No reel with no hose is the bare machine; single reel is the standard build; dual reel carries two hose runs of the selected length; the ElectricWind reel is motorized, with push button variable speed rewind; RemoteWind is a motorized reel triggered from the gun end of the hose by a pressure sensor rather than a wireless remote, with programmable rewind speed, a safety stop and a level wind guide. CRF stands for Corrosion Resistant Fittings, Dramm's swap of the brass fittings and manifolds for stainless or plated components, and it is the build to order if you run oxidizers such as ZeroTol or other peroxide chemistry. On this page CRF is offered on both the single reel and the dual reel options.
Specifications
| Tank capacity | 100 gallon |
| Motor | 1.5 HP TEFC electric - 115V 1Ph, 230V 1Ph, 230V 3Ph or 208V 3Ph (1Ph is single phase, 3Ph is three phase) |
| Motor speed | 1750 rpm on the standard motors; the two 208V three phase options are labelled by shaft speed, 1750 rpm and 3600 rpm |
| Amp draw | 13.6 A at 115V single phase, 6.8 A at 230V single phase |
| Pump | Triplex piston with stainless inner sleeves, close-coupled direct drive |
| Maximum pump output | 4 GPM |
| Maximum pressure | 550 psi with fully adjustable regulator |
| Cart | SprayTrax four wheel self-tracking, turns 360 degrees within a 7 ft circle, 15 in turf tires |
| Frame dimensions | L 60 in x W 39 in x H 63 in (frame only) |
| Hose length | No hose, 150 ft, 200 ft, 250 ft or 300 ft; dual reel builds carry the selected length on each reel |
| Reel | No reel, one or two manual convex reels with lock and variable tension drag, or a motorized ElectricWind or RemoteWind reel |
| Fittings | Brass standard; CRF (Corrosion Resistant Fittings, stainless or plated) on the single reel CRF and dual reel CRF options |
| Agitation | Pump bypass agitation to hold wettable powders in suspension |
| Spray gun | Adjustable trigger gun, straight stream to fine cone, standard on the hose equipped builds |
| Nozzle tips | Interchangeable, 0.8 mm through 3.0 mm |
| Water note | Dramm advises against running any Hydra on reverse osmosis water, which can damage even stainless components |
Configurations
| Hose Length | Motor | Reel & Fittings | Part number |
|---|---|---|---|
| No hose | 115V 1Ph | No reel | HYDRAEST1000R |
| 150 ft | 115V 1Ph | Single reel | HYDRAEST1001R150 |
| 200 ft | 115V 1Ph | Single reel | HYDRAEST1001R200 |
| 200 ft | 208V 3Ph 1750 rpm | Single reel | HYDRAEST1001R200 V33 |
| 250 ft | 115V 1Ph | Single reel | HYDRAEST1001R250 |
| 250 ft | 230V 1Ph | Single reel | HYDRAEST1001R250 V30 |
| 300 ft | 115V 1Ph | Single reel | HYDRAEST1001R300 |
| 150 ft | 230V 3Ph | Dual reel | HYDRAEST1002R150 V34 |
| 250 ft | 115V 1Ph | Dual reel | HYDRAEST1002R250 V32 |
| 300 ft | 115V 1Ph | Single reel - CRF | HYDRAEST1001R300-CRF |
| 150 ft | 230V 1Ph | Dual reel - CRF | HYDRAEST1002R150-CRF V35 |
| 200 ft | 208V 3Ph 3600 rpm | Dual reel - CRF | HYDRAEST1002R200-CRF V08 |
| 300 ft | 208V 3Ph 3600 rpm | Dual reel - CRF | HYDRAEST1002R300-CRF V32 |
| 150 ft | 115V 1Ph | ElectricWind reel | HYDRAEST100ER150 |
| 200 ft | 115V 1Ph | ElectricWind reel | HYDRAEST100ER200 |
| 250 ft | 115V 1Ph | ElectricWind reel | HYDRAEST100ER250 |
| 300 ft | 115V 1Ph | ElectricWind reel | HYDRAEST100ER300 |
| 150 ft | 115V 1Ph | RemoteWind reel | HYDRAEST100RR150 |
| 200 ft | 115V 1Ph | RemoteWind reel | HYDRAEST100RR200 |
| 250 ft | 115V 1Ph | RemoteWind reel | HYDRAEST100RR250 |
| 200 ft | 208V 3Ph 3600 rpm | RemoteWind reel | HYDRAEST100RR200 V31 |
| 300 ft | 115V 1Ph | RemoteWind reel | HYDRAEST100RR300 |
Key Features
- Four wheel self-tracking SprayTrax cart turns 360 degrees inside a 7 ft circle on 15 in turf tires
- Stainless inner sleeved triplex piston pump close-coupled to the motor - no belt, chain or gear drive
- 4 GPM at up to 550 psi through a fully adjustable regulator
- TEFC motor (totally enclosed, fan cooled) suits damp greenhouse air
- Bypass agitation holds wettable powders in suspension
- Motorized ElectricWind and RemoteWind reel options take the hand winding out of long hose runs
- CRF builds swap brass fittings and manifolds for stainless or plated components for oxidizer chemistry
Ideal Applications
- Indoor and enclosed growing where engine exhaust is not acceptable
- Greenhouse ranges and cultivation facilities with power at the aisle
- Soft floors and uneven ground that a rigid cart would rut
- Wettable powder suspensions that need continuous agitation
- Long hose run spraying from a reel mounted hose
- Drench application with a drench adaptor in place of the spray gun
- Oxidizer programs such as ZeroTol and peroxide chemistry, on the CRF builds
The gas engine version of the same cart is the Hydra SprayTrax Gas 100 Gallon, the 200 gallon electric on the same pump is the Hydra200 Electric, and BlueFlex replacement spray hose, the L-5 extension lance and the drench adaptor are sold separately.
