Dramm - Brass Eyelets and Handpick Insertion Tool

Brand: Dramm

Brass Eyelets and Handpick Insertion Tool

This is the take-off half of a Dramm dribble tube system: the brass eyelet that goes through the wall of the black poly lateral, and the tool that puts it there. Every drop needs one eyelet, and eyelet choice follows the bore of the leader tube, one for 0.060 in and 0.045 in ID tube and one for 0.075 in ID tube. The Universal Handpick insertion tool holds an eyelet on its tip, pierces the poly tubing and seats the eyelet in one leak-free motion, which is what makes several thousand drops per house practical to assemble. When you fit the dribble tube, push it past the compression end of the eyelet or the joint will pull out.

Match the eyelet to the leader tube bore, not to the pot. The 0.045 in green and 0.060 in brown tubes both run in the smaller eyelet and the 0.075 in blue tube runs in the larger one, because the two smaller bores share a 0.100 in outside diameter while the 0.075 in tube is 0.125 in outside; that outside diameter, not the bore, is what the eyelet actually grips. Get it wrong in either direction and the joint either leaks or will not go together. The eyelet doubles as an adapter on a bench you are converting, since Dramm leader tube is smaller in outside diameter than most uncompensated drip tubing and an eyelet will bring an already punched hole down to the Dramm size. The Universal Handpick insertion tool is not size specific and serves both eyelets, so order it once per crew and order eyelets by the drop count.

Specifications

Configurations

Key Features

• Brass eyelet forms the take-off from a black poly lateral to a Dramm Dribble Tube or Dribble Ring
• Two sizes cover the whole leader tube range: 0.060 in and 0.045 in ID in one eyelet, 0.075 in ID in the other
• Universal Handpick insertion tool punches the hole and sets the eyelet in one leak-free operation
• One tool fits both eyelet sizes, so a crew carries a single pick
• Compression end of the eyelet grips the dribble tube once the tube is pushed past it
• Eyelet will step an already punched hole down to Dramm's smaller outside diameter leader tube

Ideal Applications

• Assembling dribble tube benches for 5 in, 6 in and 7 in pots
• Feeding Dramm Dribble Rings on nursery stock and large containers
• Adding drops to an existing black poly lateral in the field
• Converting a bench from another uncompensated drip tube to Dramm dribble tubes
• Repairing pulled or torn drops mid-crop

Order eyelets with the Dramm Dribble Tubes and PC Dribble Rings they feed and with the matching 0.045 in, 0.060 in and 0.075 in leader tubing, and add the S3ANCHOR stake if the rings need holding in the pot.
