TrolMaster - Carbon-X Controller with cable set, Free Smartphone App (CDA-1)

Brand: TrolMaster

TrolMaster Carbon-X CO2 Alarm System (CDA-1)

The CDA-1 is the brain of the TrolMaster Carbon-X system, providing critical monitoring of CO2 levels for up to 13 separate zones or rooms. It supports high level (up to 30,000 ppm) and low level (5,000 ppm) alerts, and both limits are user-adjustable to meet local regulations for supplemental CO2 use indoors.

The Carbon-X can also control devices such as ventilation fans, dampers and main CO2 valves, and can signal the fire department by interfacing with the facility fire / alarm panel. Automatic CO2 shut-off is accomplished by wiring the main CO2 solenoid in series with a system control module. Each monitored room also requires an audio-visual alarm, and the TrolMaster app provides remote monitoring and high-CO2 notifications.

Available Options

• Model: CDA-1
• Includes: CO2 Alarm System (CDA-1), 2 x 16ft RJ12 Cable, 12V Power Adapter

Key Features

• Monitors CO2 for up to 13 zones / rooms
• User-adjustable high (up to 30,000 ppm) and low (5,000 ppm) alert levels
• Up to 13 sensors per alarm channel and up to 40 controlled outputs
• Plug and play, customizable device settings
• App connectivity for remote monitoring and alerts
• Input voltage: 100-240VAC, 50/60Hz
• Working environment: 32 to 122 deg F, humidity 90% or less
• Package dimensions: 275mm (L) x 164mm (W) x 62mm (H)

Ideal Applications

• CO2 safety monitoring in commercial indoor cultivation facilities using supplemental CO2
• Automatic CO2 shut-off and ventilation control during high-CO2 events
• Integration with facility fire / alarm panels
