Dramm - Hydra200 Electric 200 Gallon Sprayer

Brand: Dramm

Hydra200 Electric 200 Gallon Sprayer

The Hydra200 Electric puts the 200 gallon Hydra on a 1.5 HP TEFC electric motor in place of a gas engine, driving the same stainless inner sleeved triplex piston pump at 4 GPM and up to 550 psi. It sits on a powder coated steel frame with pneumatic tires and steering. This is the version for indoor and enclosed sites where engine exhaust is a problem - propagation houses, headhouses, cultivation rooms and any range with power at the end of the aisle. Output is lower than the gas Hydra200, so you are trading flow for quiet, emission free operation.

Pick the motor first, because it has to match the supply at the building. 1Ph means single phase and 3Ph means three phase: 115V 1Ph is ordinary single phase shop power and covers most of this page, while the 208V 3Ph options need a three phase feed and a circuit your electrician has signed off. The rpm figure in the option name is the motor's rated shaft speed, so 208V 3Ph 1750 rpm and 208V 3Ph 3600 rpm are the same supply with different motor speeds; Dramm's standard Hydra electric motor is a 1750 rpm unit. Next choose reel, fittings and tank, which are one line: single reel carries one hose run, dual reel carries two of the selected length, the ElectricWind reel is motorized and rewinds at variable speed while you hold the button, and RemoteWind is a motorized reel triggered from the gun end of the hose by a pressure sensor rather than a wireless remote, with programmable rewind speed, a safety stop and a level wind guide. Most of those can be ordered with a 20 gallon auxiliary tank for spot treatment or a chemical change part way through an application. Fittings last: CRF stands for Corrosion Resistant Fittings, Dramm's swap of the brass fittings and manifolds for stainless or plated parts, and it is what you buy for oxidizers such as ZeroTol or other peroxide chemistry. On this page CRF is built on the dual reel and RemoteWind reel options only.

Specifications

Configurations

Key Features

• Stainless inner sleeved triplex piston pump close-coupled to the motor - no belt, chain or gear drive
• 4 GPM at up to 550 psi through a fully adjustable regulator
• TEFC motor (totally enclosed, fan cooled) suits damp greenhouse air
• Convex reel profile with lock and variable tension drag stops birdnesting and freewheeling
• Bypass agitation holds wettable powders in suspension through a long spray
• Optional 20 gallon auxiliary tank for spot work or a mid-application chemical change
• CRF builds swap brass fittings and manifolds for stainless or plated components for oxidizer chemistry

Ideal Applications

• Indoor and enclosed growing where engine exhaust is not acceptable
• Greenhouse and nursery crop protection on long reel mounted hose runs
• Wettable powder suspensions that need continuous agitation
• Controlled environment agriculture and cultivation facilities
• Drench application with a drench adaptor in place of the spray gun
• Oxidizer programs such as ZeroTol and peroxide chemistry, on the CRF builds

The gasoline version of the same machine is on the Hydra200 Gas 200 Gallon page, a 100 gallon electric on the same pump is the Hydra SprayTrax Electric 100 Gallon, and BlueFlex replacement spray hose, the L-5 extension lance and the drench adaptor are sold separately.
