Dab Pumps - NVR Non-Return Valve for EsyBox Mini 3 - SP00002197

Brand: Dab Pumps

Complete NVR Non-Return Valve - EsyBox Mini 3 - SP00002197

DAB calls this part COMPLETE NVR on its EsyBox Mini 3 spare parts lists, which is DAB spelling for the pump non-return valve. The DAB instruction manual states that the system has an integrated non-return valve which is necessary for correct operation, and that the presence of solid bodies or sand in the water could cause malfunctioning of the valve and therefore of the system. The manual says that if you notice abnormal operation of the non-return valve it can be extracted from the system and cleaned and/or replaced. In DAB troubleshooting, a faulty non-return valve is one of the listed causes of a pump that starts without a utility request, and the remedy given is to service the non-return valve.

Position 21 on all four DAB lists. The exploded view draws it as a complete cartridge with its screw cap and sealing rings, seated in the hydraulic manifold between the outlet body group at position 22 and the tank at position 23. DAB reaches it from the special maintenance compartment: remove the access door on Face F by disengaging its 2 fixing screws with the accessory tool, unscrew the cap, then extract the cartridge with pliers without rotating it, gripping it by the jumper provided for the purpose. DAB notes that refitting the cartridge takes the force needed to compress its O-rings.

Fits

• DAB EsyBox Mini 3, all four published revisions: N.1 (product code 60179457), N.4 (60183501), N.5 (60183501) and N.6 (60212598). DAB lists this part at position 21 on every one of them.
• Stable across all four revisions. DAB uses the same item number, SP00002197, at position 21 on N.1, N.4, N.5 and N.6, so you do not need to know which revision you own before you order this part.
• The four DAB lists behind this listing are a Schuko build, product code 60179457, and Australian builds, product codes 60183501 and 60212598. DAB publishes no US list in this document series, so US buyers should check the item number against the technical data plate on their own pump before ordering.

Before You Order

• DAB prints this caution at the head of every EsyBox Mini 3 spare parts list: "Attention: check the correspondence with the revision of your product."
• DAB instruction manual, non-return valve maintenance: should one or more O-rings be lost or damaged during maintenance operations on the non-return valve, they must be replaced, otherwise the system might not work correctly.
• DAB advises cleaning the valve under running water and checking it for damage first, replacing it only if necessary.
• How to check your own pump. DAB keeps the technical data plate inside the technical compartment. Open the door on Face A, which is the top face of the pump in the vertical installation, and read the plate: DAB shows it as item 2 in Figure 3 of the EsyBox Mini 3 instruction manual, alongside the quick guide, the filling cap, the accessory tool, the motor shaft and the QR code. If you cannot make out a revision, photograph the whole plate and send it with your order.
• DAB instruction manual, maintenance section: disconnect the power supply before starting any work on the system.
• For context, four positions on this pump do change between revisions: the HMI at position 8, the power cable at position 10, the main board at position 12 and the complete motor at position 18. DAB also adds a bug filter to the list from N.4 onward. This part is not one of them.

Often Replaced With

• Kit O-Ring, DAB SP00002239, position 27. DAB states outright that O-rings lost or damaged during non-return valve maintenance must be replaced.
