DAB JETCOM Self-Priming Jet Pump

The DAB JETCOM is a single-stage self-priming centrifugal pump with an internal ejector and a technopolymer pump body. DAB specifies a cast iron motor support, a technopolymer impeller, diffuser, Venturi tube and sand guard, stainless steel adjustment rings and a carbon and ceramic mechanical seal. The motor is asynchronous, closed and cooled by external ventilation, with built-in thermal and current overload protection and a permanently connected capacitor on the single-phase version. Motor protection is IP 44 with IP 55 terminal board protection and class F insulation. All four models run on 115-230 V dual voltage at 60 Hz with 1 in NPT suction and 1 in NPT discharge.

The internal ejector is the point of the pump: it lets the JETCOM pull a prime and keep pumping even when air bubbles are present in the suction line, down to a maximum suction depth of 26 ft. That makes it the standard choice for shallow wells, cisterns, ponds and above-ground tanks where the water level sits below the pump. DAB lists it for domestic water supply, small-scale agriculture and gardening. The technopolymer body keeps the pump light and corrosion-free and DAB notes it will tolerate water carrying small quantities of sand. Liquid must be clean, non-viscous, non-aggressive, non-crystallised and chemically neutral.

Available Models

JETCOM 62 M: 0.6 HP, max head 138 ft, max flow 13.2 GPM
JETCOM 82 M: 0.8 HP, max head 154 ft, max flow 15.8 GPM
JETCOM 102 M: 1 HP, max head 177 ft, max flow 15.8 GPM
JETCOM 132 M: 1.36 HP, max head 158 ft, max flow 21.1 GPM

Specifications

Pump Type: Self-priming centrifugal with internal ejector
Power Supply: 1 x 115-230 V, 60 Hz, dual voltage
Operating Range: 1.8 to 23.3 GPM with head up to 173 ft, per DAB USA May 2025 catalog
Maximum Working Pressure: 87 psi
Maximum Suction Depth: 26 ft
Liquid Temperature: 32 F to 95 F for domestic use, 32 F to 104 F for other uses
Maximum Ambient Temperature: 104 F
Suction and Discharge: 1 in NPT and 1 in NPT
Pump Body: Technopolymer
Motor Support: Cast iron
Impeller, Diffuser, Venturi Tube and Sand Guard: Technopolymer
Adjustment Rings: Stainless steel
Mechanical Seal: Carbon and ceramic
Motor Protection: IP 44
Terminal Board Protection: IP 55
Insulation Class: F
Installation: Horizontal, fixed or portable
Certification: CSA and UL, per DAB USA 60 Hz price list

Key Features

Internal ejector gives strong suction and lets the pump run with air bubbles in the line
Self-primes from up to 26 ft below the pump
Technopolymer pump body will not rust and keeps shipping and mounting weight low
Cast iron motor support gives the pump a rigid mounting foot despite the plastic wet end
Dual voltage 115-230 V wiring on all four models
Built-in thermal and current overload protection with permanently connected capacitor
Fan guard shaped to act as an air conveyor for motor cooling
Tolerates water carrying small quantities of sand

Ideal Applications

Shallow well water supply where the water table is above 26 ft of lift
Cistern, storage tank and rain barrel pumping
Residential pressure boosting
Small to medium irrigation and garden watering
Pond and surface water transfer
Small-scale agriculture and hobby farm water supply
Portable or seasonal water supply duties

Dab Pumps - JETCOM Self-Priming Shallow Well Jet Pump

Brand: Dab Pumps
