Dab Pumps - Clear Answer Submersible Pond and Water Feature Pump 115V

Brand: Dab Pumps

DAB Clear Answer Submersible Clean Water Pump

The DAB Clear Answer is a 115 V single phase submersible pump for clean water, published by DAB as a pond and water feature pump: circulating water in garden ponds, driving waterfalls, and running fountains and play water features. It installs either vertically or horizontally, so it can lie on a pond floor or stand in a basin. The pump body, top body and base are glass-filled polypropylene, the impeller is Noryl, the upper and lower motor casings are cast aluminum and the rotor shaft is quenched AISI 416 stainless steel running in a triple lip NBR seal. The motor is an induction type, closed and cooled by the liquid being pumped, with built-in thermic overload protection and a capacitor permanently in circuit. Three sizes cover the range, from 31 GPM up to 70 GPM. None of the three is supplied with a float switch - DAB publishes no float on this family - so if you need level control, plan on an external switch or controller.

DAB's published application for Clear Answer is water circulation rather than intermittent basin pump-out: garden ponds, waterfalls, streams and spillways, fountains and architectural water features, and continuous turnover in tanks and holding basins. DAB's stated liquid is pond water without fibres: clear water carrying particles up to 1/3 in, within each model's rated size. All three models share a 1-1/4 in NPT discharge, a 16 ft cord and a 16 ft maximum submersion.

Available Models

• Clear Answer 1: 1/4 HP, no float, max flow 31 GPM, max head 21 ft
• Clear Answer 2: 1/3 HP, no float, max flow 44 GPM, max head 30 ft
• Clear Answer 3: 1/2 HP, no float, max flow 70 GPM, max head 34 ft

Specifications

• Power supply: 115 V, 60 Hz, single phase
• Power input P1: 280 W on Clear Answer 1, 370 W on Clear Answer 2, 820 W on Clear Answer 3
• Rated current: 2.4 A, 3.4 A and 7.6 A respectively
• Maximum pressure: 9 psi on Clear Answer 1, 12 psi on Clear Answer 2, 14 psi on Clear Answer 3
• Family operating range: 4.4 to 70 GPM with head up to 34 ft, per DAB's May 2025 USA catalog
• Discharge connection: 1-1/4 in NPT
• Maximum solids: 0.3 in on Clear Answer 1, 0.4 in on Clear Answer 2 and 3
• Maximum submersion: 16 ft
• Liquid temperature: 32 F to 95 F
• Maximum ambient temperature: 104 F
• Liquid quality: pond waters without fibers - clear water carrying particles up to the model's rated size, which DAB gives as up to 1/3 in across the range
• Motor protection: NEMA 6P
• Motor insulation class: F
• Power cord: 16 ft
• Overall height 10.5 in, body 5.5 in by 6.1 in
• Materials: glass-filled polypropylene pump body, top body and base; Noryl impeller; cast aluminum upper and lower motor casings; quenched AISI 416 stainless steel rotor shaft; NBR 70 O rings and triple lip seal; stainless steel 316 lock nut
• Installation: fixed or portable, vertical or horizontal
• Certification: in compliance with CSA Standards C22.2 No. 108-14 and UL Standard No. 778, per DAB

Key Features

• Three sizes from 31 GPM to 70 GPM on one 1-1/4 in NPT discharge
• Induction motor closed and cooled by the pumped liquid, for sustained circulation duty
• Cast aluminum motor casings with a wear-resistant shaft and triple lip seals
• Capacitor permanently in circuit and built-in thermic overload protection
• Mounts vertically or horizontally
• NEMA 6P motor protection
• Ships with a 16 ft power cable and plug and a self-sealing fitting
• Supplied without a float switch - pair with an external level control if you need automatic operation

Ideal Applications

• Garden pond and water garden circulation
• Waterfalls, streams and spillways
• Fountains and architectural water features
• Continuous turnover in tanks and holding basins
• Filtration and aeration loop feed
• Clean water transfer with an external switch or manual control
