BVV - 3.5CFM Dry Floating Scroll Vacuum Pump #1 Candy Drying Vacuum Pump
Brand: BVV
3.5CFM Dry Floating Scroll Vacuum Pump
1 Candy Drying Vacuum Pump
Oil and Maintenance Free!
Introducing the BSVF6 Vacuum Pump, equipped with cutting-edge patented floating scroll technology for unparalleled performance. This pump boasts a 3.5CFM (100 L/min) pump speed and an ultimate pressure of 25 Microns ( 0.03 mbar), making it a powerhouse in creating and maintaining vacuums. The 100% oil-free design ensures clean and efficient operation, while the brushless DC motor, with 350W motor power and 200W installed power, provides reliability and longevity. With a compact size ideal for portable equipment, this vacuum pump offers unlimited vapor tolerance and a noise level as low as 55 dB(A) with its case. The SVF-E2-100 is maintenance-free, featuring a robust build with inlet/outlet connections in KF-25, air-cooled cooling system, and a wide ambient temperature range from -40C to 50C. Elevate your vacuum processes with this advanced, compact, and powerful solution.
Specifications
| Model | BSVF6 |
| Pump Speed | 100 L/min |
| Ultimate Pressure | 0.03 mbar (25 Micron) |
| Motor Power | 350 W |
| Installed Power | 200 W |
| Motor Type | Brushless DC Motor |
| DC Voltage | 48 VDC |
| AC Voltage (with adapter) | 100 - 240 VAC |
| Maximum Speed | 4000 RPM |
| Vapor Tolerance | Unlimited |
| Maximum Inlet Speed | Unlimited |
| Maximum Outlet Speed | 1 barg |
| Noise Level (With Frame) | 60 dB(A) |
| Noise Level(With Case) | 55 dB(A) |
| Weight (With Frame) | 7.5 kg |
| Weight (With Case) | 8.5 kg |
| Dimensions (With Frame) | 324x225x175mm |
| Dimensions (With Case) | 394x236x189mm |
| Inlet/Outlet Connection | KF-25 or G 3/8 |
| Cooling System | Air - Cooled |
| Ambient Temperature | -40C to 50C |
